MH3500S-24 3500W 230VAC Pure Sine Wave Hybrid Solar Inverter with MPPT

3500W 230VAC Pure Sine Wave Hybrid Solar Inverter with MPPT is designed for household hybrid and off-grid solar power systems. It converts DC power from solar batteries into 230VAC power for connected loads. The inverter combines solar energy management with battery storage and backup power functions. With pure sine wave output and built-in MPPT functionality, it can be integrated into household solar systems that require stable AC power and solar energy management.

Purchasing Information
MOQ: 100 pcs
Lead Time: 35 days
Payment Terms: TT / DP / LC
Shipping Methods: Maritime shipping / Air freight / Road transportation

For bulk orders, buyers can confirm the required quantity, target market, system configuration, packaging requirements, and technical specifications before production.

Technical Specifications
Item Specification
Product Name 3500W 230VAC Pure Sine Wave Hybrid Solar Inverter with MPPT
Model MH3500S-24
Rated Power 3500W
AC Output Voltage 230VAC
Battery Voltage 24V

Bottom View

vbeyqmba1789466861

1. AC input

2. AC output

3. PV input

4. Battery input

5. Grounding

System Diagram

wwiickqh1789467013

Technical Data

MODEL CM3500-24S CM3500-24N
Capacity 3500VA/3500W 3500VA/3500W
Parallel Capability NO NO
Lithium Battery Activation YES(By PV) NO
Lithium battery Communication NO NO
INPUT
Nominal Voltage 230VAC
Acceptable Voltage Range 170-280VAC(For personal Computer);90-280VAC(For Home Appliances)
Frequency 50/60 Hz (Auto sensing)
OUTPUT
Nominal Voltage 220/230VAC±5%
Rated Power 3500VA/3500W 3500VA/3500W
Battery Mode Power 3000VA/3000W 3000VA/3000W
Surge Power 7000VA 7000VA
Frequency 50/60 Hz
Waveform Pure Sine wave
Transfer Time 10ms(For personal Computer);20ms(For Home Appliances)
Peak Efficiency (PV to INV) 96%
Peak Efficiency (Battery to INV) 93%
Overload Protection 5s@ >=140% load; 10s@100%~140% load
Crest Factor 3:1
Admissible Power Factor 0.6~1 (inductive or capacitive)
BATTERY
Battery Voltage 24Vdc 24Vdc
Floating Charge Voltage 27Vdc 27Vdc
OverCharge Protection 32Vdc 32Vdc
Charging Method CC/CV
SOLAR CHARGER & AC CHARGER
Solar Charger TYPE MPPT
Max.PV Array Power 4000W 4000W
Max. PV Array Open Circuit Voltage 500VDC
PV Array MPPT Voltage Range 30VDC~500VDC
Max. Solar Input Current 15A
Max. Solar Charge Current 100A 100A
Max. AC Charge Current 60A 60A
Max. Charge Current(AC+PV) 100A 100A
PHYSICAL
Dimensions, D x W x H(mm) 334x293x98.5
Package Dimensions, D x W x H(mm) 402x368x174
Net Weight (Kgs) 4.4 4.4
Gross weight(Kgs) 5.25 5.25
Communication Interface RJ45 For Wifi
ENVIRONMENT
Operating Temperature Range -10°C to 55°C
Storage temperature -15°C~ 60°C
Humidity 5% to 95% Relative Humidity (Non-condensing)
Ingress Protection IP21

Product specifications are subject to change without further notice

Inquiry Now


  • The 3500W 230VAC Pure Sine Wave Hybrid Solar Inverter is suitable for:

    • Household off-grid solar power systems
    • Home backup power systems
    • Residential solar battery storage
    • Small-scale solar energy systems
    • Remote areas with limited grid access
